Washing & Extraction

Industrial Washing Machine

Heavy-duty SS 304 garment & denim washing machines.

Front-loading / barrel-type industrial washing machines in SS 304 with 80 mm drive shaft, inverter drive and forward-reverse action — for garment, denim and acid washing.

Capacity: 100 kg+ (as per requirement)
Built by: Two Star, Lahore

Request quote WhatsApp

Download brochure (PDF)

Overview

Designed for round-the-clock garment and denim laundries, our industrial washing machine uses a roller-style drum with forward and reverse rotation for the finest wash results. Inner and outer cylinders are stainless steel, with argon-welded drums and an 80 mm drive shaft for long life.

A safety switch stops the cylinder automatically when the door opens, and the V-belt drive with INVT inverter keeps operation smooth and almost silent. Available as front-loading, barrel-type and acid wash models.

Key features

Roller style with forward & reverse rotation
Timer & button controls from start to stop
SS inner & outer cylinder — anti-corrosion
Door safety switch stops the drum automatically
V-belt drive — almost silent operation
Front-loading, barrel-type & acid wash models

Technical specifications

SPEC-007

Industrial Washing Machine specifications
Drum size	4' × 7'-6"
Outer size	4'-6" × 8'
Outer shell sheets	2 mm SS 304
Outer shell blind	4 mm SS 304
Inner drum sheets	3 mm SS 304
Inner drum blind	5 mm SS 304
Drum drive shaft	80 mm
Bearings	UCP 215 & 213
Main drive shaft	MS 70 mm
Welding	Argon, all SS nuts & bolts
Drive motor	10 HP, 900 RPM
Inverter	New INVT
Temperature gauge	Electronic & manual
Panel	Reverse / forward with LG accessories

Optional add-ons

Touch screen PLC system Pneumatic drain Air brake system Indirect heating (automatic constant temperature) Ratio water inlet (with PLC) INVT inverter Mixing & dosing tank (50 L / 100 L)
